Znse CO2 Plane-convex focusing laser lens
Original price was: $22.00.$19.00Current price is: $19.00.
14% Off
Znse Plane-convex focusing lens is applied to CO2 laser. One side is flat and the other side is convex.
Material: USA CVD Znse
Application: Laser marking, engraving and cutting machine，etc
Diameter: 12/18 /19.05 /20mm
Focal length:1.5″(38.1mm) 2″(50.8mm) 2.5″(63.5mm) 3″(76.2mm) 4″(101.6mm) 5″(127mm)
——-
Price:by case
Model:Z-003
Size:custom,etc
Min.order Quantity: 1 pieces
Lead time:1-4 weeks or depends on order quantity
Description
Znse Plane-convex focusing lens is applied to CO2 laser. One side is flat and the other side is convex. The substrate is laser-grade CVD ZnSe and coated with the double-sided anti-reflective film. The convex surface should face the perpendicular incident light beam and the plane should face the workpiece.
Znse lens is a commonly used optical glass material in the infrared band with a transmission band of 600nm-16μm. It has low absorption and thermal shock resistance, and is commonly used in thermal imaging systems, as well as in some visible optical systems, and can be used as a substrate for a variety of optical components. It is important to note that zinc selenide is a toxic material, so please wear gloves when using it and wash your hands afterwards.
Specifications
Diameter Tolerance: +0/-0.13mm/+0.000” -0.005”
Thickness Tolerance: ±0.25mm/±0.010”
FL Tolerance: <±2%
Centration: <3 arc minutes
Clear Aperture >90%
Surface Figure <λ/2 per 1″[email protected]
Surface Quality 40-20 scratch and dig
AR/AR coating R<0.5% per surface @ 10.6um
2. ZnSe Singlet Positive Meniscus Lenses (wavelength 10.6um)
Specifications
Diameter Tolerance: +0/-0.13mm/+0.000” -0.005”
Thickness Tolerance: ±0.25mm/±0.010”
FL Tolerance <±2%
Centration <3 arc minutes
Clear Aperture >90%
Surface Figure <λ/2 per 1″[email protected]
Surface Quality 40-20 scratch and dig
AR/AR coating R<0.5% per surface @ 10.6um
Specification
| Material: USA CVD Znse | FL Tolerance<±1% |
| Diameter tolerance: +0/0.12mm | Clear Aperture>90% |
| Wavelength: 10.6um | Surface Figure<2 per 1″Dia |
| Thickness tolerance: +0/+0.2mm | AR/AR coating R<0.5% per surface |
| Transmittance: 99% | Surface Quality: 20-10 scratch and dig |
Inspection:Each lens be tested before packing,a formal tested report will be provided.
Application of our lenses:avionics,astronomy,military,medical,scientifics,laser etc…
FAQ:
1. Are you manufacturure? can we see your factory?
Yes.
2. Do you have test report?
Yes, we offer full size test report, about size, focal length, flatness, coating curve, coating plate.
3.What is your production quantity everymonth?
It depands on the lens size and precison.
4.What is the Minimum quantity?
1pc
5.What is your delivery time?
samples: 10-20days
6.How should we do if the quality is not good?
Repair or return money.
