Porro Prism (optical glass BK7 Quartz UV Fused Silica JGS1 Sapphire ZnSe)
Original price was: $5.00.$2.80Current price is: $2.80.
44% Off
Paul prisms are most often used in pairs as a combination of double Paul prisms, with the second prism rotated 90° relative to the first.
Transmittance: >95%
Shape: Porro Prism
Material: K9 Quartz Bk7 Sapphire Germanium Silicon Znse,etc (Can be Customized)
Min.order Quantity: 1 pieces
Lead time:1-4 weeks or depends on order quantity
Description
Porro Prism, also known as Porro prism, is a refractive triangular prism used in optical instruments to modify the orientation of images. Paul prisms are isosceles right-angled prisms shaped from glass blocks with the end planes facing the right angle. In use, the light enters from the largest rectangular surface in the triangular prism, undergoes two total reflections on the inclined surface, and then penetrates the original incident plane and exits. Because the light only enters and exits in a normal state, the prism does not have the effect of dispersion. But the image passing through the Paul prism will be flipped 180°, and will travel in the original direction, that is, the direction of Paul prism travel is also changed by 180°. But because the image is reflected twice, the handedness is unchanged.
Application field:
Optical Instruments
High-end equipment
Military Industry
Space Flight and Aviation
Specification
Material | optical glass |
Dimension | Customized |
Diameter Tolerance | +0.1, -0.1 mm |
Thickness Tolerance | +0.1, -0.1 mm |
Angle Tolerance | ±30 Arc Seconds |
Surface Flatness | 1/4 L @632.8nm |
Surface Quality | 60-40 scratch and dig |
Protective Bevel | 0.25 mm x 45° |
Coating | Customized |
Inspection:Each lens be tested before packing,a formal tested report will be provided.
Application of our lenses:avionics,astronomy,military,medical,scientifics,laser etc…
Packaging & Delivery.
Packaging Details:
Inner packing——-special protective packing for optical products.
Outer packing——carton, Shock absorption material and bubble wrap
Delivery Time
7-20days
Delivery: Generally, we use the Fedex, DHL, UPS, TNT, Shunfeng, etc.
Please note it before delivery. Transit time deponds on the express and destination.
By the way, we would re-check all the details before delivery.
