Factory Direct Multi-Sided Penta Prism Optical Lenses
Original price was: $11.00.$7.50Current price is: $7.50.
32% Off
Usage: Beam Steering and Optical System Alignment
Type: Multi-Sided Penta Lenses
Transmittance: >95%
Shape: Pentagonal prism
Material: K9 Quartz Bk7 Sapphire Germanium Silicon Znse
Lenses Color: Clear
Description
Penta Prism Lens are widely used in laser level, Image system, precision system, and optical area. For penta prism, the deviation angle of 90° is independent of the orientation of the prism, thus it is particularly important and wide in application which the prism orientation cannot be precisely controlled, we can produce high precision penta angle prism,and make coating according to customer’s request.
Application
1.Plumb Level
2.Surveying, Alignment
3.Range finding and Optical Tooling
4.Viewfinder of single-lens reflex cameras
Specification
|
Material:
|
BK7,H-K9L,UV Grade Fused Silica, SF14 glass ect
|
|
Dimension range
|
from 1mm~300mm in any optical axis
|
|
Dimension Tolerance:
|
±0.10mm,±0.025mm,±0.01mm
|
|
Surface Accuracy
|
1λ,λ/10, λ/20
|
|
Surface quality:
|
60-40,40-20, 20-10 scratch and dig
|
|
Angle Tolerance:
|
±3arc min—±5 arc sec
|
|
Bevel:
|
0.2-0.5mmx45°
|
|
Coating
|
upon request
|
Inspection:Each lens be tested before packing,a formal tested report will be provided.
Application of our lenses:avionics,astronomy,military,medical,scientifics,laser etc…
